NiFi Toolkit - CLI - For NiFi 1.10
Along with the updated Apache NiFi server, the NiFi 1.10 release also updated the Command Line Interface with some updated and new features. Let's check them out.
Cool Tools
S2S.sh - send data to Apache NiFi via the CLI.
Formatted as such:
[{"attributes":{"key":"value"},"data":"stuff"}]
Examples
registry import-flow-version
Get Into Interactive Mode
./cli.sh
Get Parameter Contexts (simple or json format)
** nifi list-param-contexts** -u http://localhost:8080 -ot simple
Export Parameter Context
nifi export-param-context -u http://localhost:8080 -verbose --paramContextId 8067d863-016e-1000-f0f7-265210d3e7dc
Get Services
nifi get-services -u http://localhost:8080
NiFi Dump
../bin/nifi.sh dump filedump.txt
NiFi home: /Users/tspann/Documents/nifi-1.10.0
Bootstrap Config File: /Users/tspann/Documents/nifi-1.10.0/conf/bootstrap.conf
2019-11-18 17:08:04,921 INFO [main] org.apache.nifi.bootstrap.Command Successfully wrote thread dump to /Users/tspann/Documents/nifi-1.10.0/filedump.txt
NiFi Diagnostics
../bin/nifi.sh diagnostics diag.txt
Java home:
NiFi home: /Users/tspann/Documents/nifi-1.10.0
Bootstrap Config File: /Users/tspann/Documents/nifi-1.10.0/conf/bootstrap.conf
2019-11-18 17:11:09,844 INFO [main] org.apache.nifi.bootstrap.Command Successfully wrote diagnostics information to /Users/tspann/Documents/nifi-1.10.0/diag.txt
2019-11-18 17:11:10,041 INFO [main] org.apache.nifi.bootstrap.Command gopherProxySet = false
2019-11-18 17:11:10,042 INFO [main] org.apache.nifi.bootstrap.Command awt.toolkit = sun.lwawt.macosx.LWCToolkit
2019-11-18 17:11:10,042 INFO [main] org.apache.nifi.bootstrap.Command java.specification.version = 11
2019-11-18 17:11:10,042 INFO [main] org.apache.nifi.bootstrap.Command sun.cpu.isalist =
2019-11-18 17:11:10,042 INFO [main] org.apache.nifi.bootstrap.Command sun.jnu.encoding = UTF-8
2019-11-18 17:11:10,042 INFO [main] org.apache.nifi.bootstrap.Command java.class.path = /Users/tspann/Documents/nifi-1.10.0/./conf:/Users/tspann/Documents/nifi-1.10.0/./lib/jetty-schemas-3.1.jar:/Users/tspann/Documents/nifi-1.10.0/./lib/slf4j-api-1.7.26.jar:/Users/tspann/Documents/nifi-1.10.0/./lib/stanford-english-corenlp-2018-02-27-models.jar:/Users/tspann/Documents/nifi-1.10.0/./lib/jcl-over-slf4j-1.7.26.jar:/Users/tspann/Documents/nifi-1.10.0/./lib/javax.servlet-api-3.1.0.jar:/Users/tspann/Documents/nifi-1.10.0/./lib/logback-classic-1.2.3.jar:/Users/tspann/Documents/nifi-1.10.0/./lib/nifi-properties-1.10.0.jar:/Users/tspann/Documents/nifi-1.10.0/./lib/nifi-nar-utils-1.10.0.jar:/Users/tspann/Documents/nifi-1.10.0/./lib/nifi-api-1.10.0.jar:/Users/tspann/Documents/nifi-1.10.0/./lib/nifi-framework-api-1.10.0.jar:/Users/tspann/Documents/nifi-1.10.0/./lib/jul-to-slf4j-1.7.26.jar:/Users/tspann/Documents/nifi-1.10.0/./lib/logback-core-1.2.3.jar:/Users/tspann/Documents/nifi-1.10.0/./lib/log4j-over-slf4j-1.7.26.jar:/Users/tspann/Documents/nifi-1.10.0/./lib/nifi-runtime-1.10.0.jar:/Users/tspann/Documents/nifi-1.10.0/./lib/java11/javax.annotation-api-1.3.2.jar:/Users/tspann/Documents/nifi-1.10.0/./lib/java11/jaxb-core-2.3.0.jar:/Users/tspann/Documents/nifi-1.10.0/./lib/java11/javax.activation-api-1.2.0.jar:/Users/tspann/Documents/nifi-1.10.0/./lib/java11/jaxb-impl-2.3.0.jar:/Users/tspann/Documents/nifi-1.10.0/./lib/java11/jaxb-api-2.3.0.jar
2019-11-18 17:11:10,042 INFO [main] org.apache.nifi.bootstrap.Command java.vm.vendor = Amazon.com Inc.
2019-11-18 17:11:10,042 INFO [main] org.apache.nifi.bootstrap.Command javax.security.auth.useSubjectCredsOnly = true
2019-11-18 17:11:10,043 INFO [main] org.apache.nifi.bootstrap.Command sun.arch.data.model = 64
2019-11-18 17:11:10,043 INFO [main] org.apache.nifi.bootstrap.Command sun.font.fontmanager = sun.font.CFontManager
2019-11-18 17:11:10,043 INFO [main] org.apache.nifi.bootstrap.Command java.vendor.url = https://aws.amazon.com/corretto/
2019-11-18 17:11:10,043 INFO [main] org.apache.nifi.bootstrap.Command user.timezone = America/New_York
2019-11-18 17:11:10,043 INFO [main] org.apache.nifi.bootstrap.Command org.apache.nifi.bootstrap.config.log.dir = /Users/tspann/Documents/nifi-1.10.0/logs
2019-11-18 17:11:10,043 INFO [main] org.apache.nifi.bootstrap.Command os.name = Mac OS X
2019-11-18 17:11:10,043 INFO [main] org.apache.nifi.bootstrap.Command java.vm.specification.version = 11
2019-11-18 17:11:10,043 INFO [main] org.apache.nifi.bootstrap.Command nifi.properties.file.path = /Users/tspann/Documents/nifi-1.10.0/./conf/nifi.properties
2019-11-18 17:11:10,043 INFO [main] org.apache.nifi.bootstrap.Command sun.java.launcher = SUN_STANDARD
2019-11-18 17:11:10,043 INFO [main] org.apache.nifi.bootstrap.Command user.country = US
2019-11-18 17:11:10,043 INFO [main] org.apache.nifi.bootstrap.Command sun.boot.library.path = /Library/Java/JavaVirtualMachines/amazon-corretto-11.jdk/Contents/Home/lib
2019-11-18 17:11:10,043 INFO [main] org.apache.nifi.bootstrap.Command app = NiFi
2019-11-18 17:11:10,043 INFO [main] org.apache.nifi.bootstrap.Command sun.java.command = org.apache.nifi.NiFi
2019-11-18 17:11:10,043 INFO [main] org.apache.nifi.bootstrap.Command jdk.debug = release
2019-11-18 17:11:10,043 INFO [main] org.apache.nifi.bootstrap.Command org.apache.jasper.compiler.disablejsr199 = true
2019-11-18 17:11:10,043 INFO [main] org.apache.nifi.bootstrap.Command sun.cpu.endian = little
2019-11-18 17:11:10,043 INFO [main] org.apache.nifi.bootstrap.Command user.home = /Users/tspann
2019-11-18 17:11:10,044 INFO [main] org.apache.nifi.bootstrap.Command user.language = en
2019-11-18 17:11:10,044 INFO [main] org.apache.nifi.bootstrap.Command java.specification.vendor = Oracle Corporation
2019-11-18 17:11:10,044 INFO [main] org.apache.nifi.bootstrap.Command java.version.date = 2019-07-16
2019-11-18 17:11:10,044 INFO [main] org.apache.nifi.bootstrap.Command java.home = /Library/Java/JavaVirtualMachines/amazon-corretto-11.jdk/Contents/Home
2019-11-18 17:11:10,044 INFO [main] org.apache.nifi.bootstrap.Command file.separator = /
2019-11-18 17:11:10,044 INFO [main] org.apache.nifi.bootstrap.Command java.vm.compressedOopsMode = Zero based
2019-11-18 17:11:10,044 INFO [main] org.apache.nifi.bootstrap.Command line.separator =
2019-11-18 17:11:10,044 INFO [main] org.apache.nifi.bootstrap.Command java.specification.name = Java Platform API Specification
2019-11-18 17:11:10,044 INFO [main] org.apache.nifi.bootstrap.Command java.vm.specification.vendor = Oracle Corporation
2019-11-18 17:11:10,050 INFO [main] org.apache.nifi.bootstrap.Command javax.xml.xpath.XPathFactory:http://saxon.sf.net/jaxp/xpath/om = net.sf.saxon.xpath.XPathFactoryImpl
2019-11-18 17:11:10,050 INFO [main] org.apache.nifi.bootstrap.Command java.awt.graphicsenv = sun.awt.CGraphicsEnvironment
2019-11-18 17:11:10,051 INFO [main] org.apache.nifi.bootstrap.Command java.awt.headless = true
2019-11-18 17:11:10,051 INFO [main] org.apache.nifi.bootstrap.Command java.protocol.handler.pkgs = sun.net.www.protocol
2019-11-18 17:11:10,051 INFO [main] org.apache.nifi.bootstrap.Command sun.management.compiler = HotSpot 64-Bit Tiered Compilers
2019-11-18 17:11:10,051 INFO [main] org.apache.nifi.bootstrap.Command java.runtime.version = 11.0.4+11-LTS
2019-11-18 17:11:10,051 INFO [main] org.apache.nifi.bootstrap.Command user.name = tspann
2019-11-18 17:11:10,051 INFO [main] org.apache.nifi.bootstrap.Command java.net.preferIPv4Stack = true
2019-11-18 17:11:10,051 INFO [main] org.apache.nifi.bootstrap.Command path.separator = :
2019-11-18 17:11:10,051 INFO [main] org.apache.nifi.bootstrap.Command java.security.egd = file:/dev/urandom
2019-11-18 17:11:10,051 INFO [main] org.apache.nifi.bootstrap.Command org.jruby.embed.localvariable.behavior = persistent
2019-11-18 17:11:10,051 INFO [main] org.apache.nifi.bootstrap.Command os.version = 10.14.6
2019-11-18 17:11:10,051 INFO [main] org.apache.nifi.bootstrap.Command java.runtime.name = OpenJDK Runtime Environment
2019-11-18 17:11:10,051 INFO [main] org.apache.nifi.bootstrap.Command file.encoding = UTF-8
2019-11-18 17:11:10,052 INFO [main] org.apache.nifi.bootstrap.Command sun.net.http.allowRestrictedHeaders = true
2019-11-18 17:11:10,052 INFO [main] org.apache.nifi.bootstrap.Command jnidispatch.path = /var/folders/t5/xz5j50wx2rl8kd3021lkbn800000gn/T/jna--864347536/jna3349001211756681540.tmp
2019-11-18 17:11:10,052 INFO [main] org.apache.nifi.bootstrap.Command java.vm.name = OpenJDK 64-Bit Server VM
2019-11-18 17:11:10,052 INFO [main] org.apache.nifi.bootstrap.Command jna.platform.library.path = /usr/lib:/usr/lib
2019-11-18 17:11:10,052 INFO [main] org.apache.nifi.bootstrap.Command java.vendor.version = Corretto-11.0.4.11.1
2019-11-18 17:11:10,052 INFO [main] org.apache.nifi.bootstrap.Command jna.loaded = true
2019-11-18 17:11:10,052 INFO [main] org.apache.nifi.bootstrap.Command java.vendor.url.bug = https://github.com/corretto/corretto-11/issues/
2019-11-18 17:11:10,052 INFO [main] org.apache.nifi.bootstrap.Command jetty.git.hash = afcf563148970e98786327af5e07c261fda175d3
2019-11-18 17:11:10,052 INFO [main] org.apache.nifi.bootstrap.Command java.io.tmpdir = /var/folders/t5/xz5j50wx2rl8kd3021lkbn800000gn/T/
2019-11-18 17:11:10,052 INFO [main] org.apache.nifi.bootstrap.Command java.version = 11.0.4
2019-11-18 17:11:10,052 INFO [main] org.apache.nifi.bootstrap.Command user.dir = /Users/tspann/Documents/nifi-1.10.0
2019-11-18 17:11:10,052 INFO [main] org.apache.nifi.bootstrap.Command os.arch = x86_64
2019-11-18 17:11:10,052 INFO [main] org.apache.nifi.bootstrap.Command nifi.bootstrap.listen.port = 55105
2019-11-18 17:11:10,052 INFO [main] org.apache.nifi.bootstrap.Command java.vm.specification.name = Java Virtual Machine Specification
2019-11-18 17:11:10,052 INFO [main] org.apache.nifi.bootstrap.Command java.awt.printerjob = sun.lwawt.macosx.CPrinterJob
2019-11-18 17:11:10,053 INFO [main] org.apache.nifi.bootstrap.Command sun.os.patch.level = unknown
2019-11-18 17:11:10,053 INFO [main] org.apache.nifi.bootstrap.Command bridj.quiet = true
2019-11-18 17:11:10,053 INFO [main] org.apache.nifi.bootstrap.Command java.library.path = /Users/tspann/Library/Java/Extensions:/Library/Java/Extensions:/Network/Library/Java/Extensions:/System/Library/Java/Extensions:/usr/lib/java:.
2019-11-18 17:11:10,053 INFO [main] org.apache.nifi.bootstrap.Command java.vendor = Amazon.com Inc.
2019-11-18 17:11:10,053 INFO [main] org.apache.nifi.bootstrap.Command java.vm.info = mixed mode
2019-11-18 17:11:10,053 INFO [main] org.apache.nifi.bootstrap.Command java.vm.version = 11.0.4+11-LTS
2019-11-18 17:11:10,053 INFO [main] org.apache.nifi.bootstrap.Command sun.io.unicode.encoding = UnicodeBig
2019-11-18 17:11:10,053 INFO [main] org.apache.nifi.bootstrap.Command java.class.version = 55.0
Resources
